| General |
| Device Type |
Security appliance |
| Height (Rack Units) |
2U |
| Installed Modules Qty (Max) |
1 ( 2 ) |
| Width |
19 in |
| Depth |
26.5 in |
| Height |
3.5 in |
| Processor / Memory / Storage |
| RAM |
12 GB |
| Flash Memory |
2 GB |
| Networking |
| Form Factor |
Rack-mountable |
| Ports Qty |
6 |
| Connectivity Technology |
Wired |
| Data Link Protocol |
Ethernet, Fast Ethernet, Gigabit Ethernet |
| Network / Transport Protocol |
IPSec |
| Performance |
Firewall throughput: 10 Gbps ? VPN throughput: 3 Gbps ? Connection rate: 200000 connections per second |
| Capacity |
Concurrent sessions: 2000000 ? IPSec VPN peers: 10000 ? Virtual interfaces (VLANs): 250 ? SSL VPN peers: 2 ? Nodes: unlimited |
| Features |
Firewall protection, VPN support, load balancing, VLAN support |
| Encryption Algorithm |
DES |
| Expansion / Connectivity |
| Expansion Slots |
2 (total) / 1 (free) x expansion slot ? 4 (total) / 4 (free) x |
| Interfaces |
2 x 1000Base-T (management) – RJ-45 ? 2 x USB 2.0 – Type A ? 1 x management – RJ-45 ? 1 x management ? 6 x 1000Base-T – RJ-45 |
| Miscellaneous |
| Cables Included |
2 x network cable |
| Rack Mounting Kit |
Included |
| Compliant Standards |
CISPR 22 Class A, BSMI CNS 13438 Class A, CISPR 24, EN 61000-3-2, VCCI Class A ITE, EN 61000-3-3, EN55024, EN55022 Class A, EN50082-1, AS/NZS 60950-1, ICES-003 Class A, FCC CFR47 Part 15, EN300-386, UL 60950-1, IEC 60950-1, EN 60950-1, CSA C22.2 No. 60950-1 |
| Power |
| Power Device |
Internal power supply – hot-plug |
| Voltage Required |
AC 120/230 V ( 50/60 Hz ) |
| Environmental Parameters |
| Min Operating Temperature |
32 ?F |
| Max Operating Temperature |
104 ?F |
| Humidity Range Operating |
10 – 90% (non-condensing) |
