JW678A Specification
JW678A Specification |
|
|
Product Model |
Aruba 7010 (RW) 16p 150W PoE+ 10/100/1000BASE-T 1G BASE-X SFP 32 AP and 2K Clients Controller |
|
Maximum campus AP licenses |
32 |
|
Maximum remote AP licenses |
32 |
|
Maximum concurrent users/devices |
2,048 |
|
Maximum VLANs |
4,094 |
|
Active firewall sessions |
32,768 |
|
Concurrent GRE tunnels |
512 |
|
Concurrent IPsec sessions |
1,024 |
|
Mobility Access Switch tunneled-node ports |
1,024 |
|
Firewall throughput |
4 Gbps |
|
Encrypted throughput (3DES, AES-CBC) |
2.4 Gbps |
|
Encrypted throughput (AES-CCM) |
3.4 Gbps |
|
Form factor/footprint |
1 rack unit |
|
Auto-negotiating 10/100/1000BASE-T |
16 |
|
Gigabit Ethernet ports (GBIC or SFP) |
2 SFP |
|
USB 2.0 |
Yes |
|
Management/status LEDs |
Yes (2) |
|
LINK/ACT and status LEDs |
Yes |
|
LCD panel and navigation buttons |
No |
|
Console port |
Yes (micro USB/RJ-45) |
|
Out-of-band management port |
Yes |
|
PoE Role/Mode |
Power Source Equipment (PSE) |
|
PoE In or Out |
Out |
|
Number of PoE+ capable Ports |
12 |
|
Max concurrent of PoE Ports |
12 |
|
Max concurrent PoE+ Ports |
5 |
|
PoE Power Budget |
150W |
|
Dimension (H ? W ? D) |
4.42 cm x 31.75 cm x 33.7 cm (1.74 ?? x 12.75 ?? x 13.3 ??) |
|
Weight |
3.4 kg (7.5 lbs) |
|
MTBF (hours, @ 25C) |
232,843 |
|
Operating temperature |
0 ? C to 40 ? C |
|
Storage temperature |
-40 ? C to 70 ? C |
|
Humidity/storage humidity |
10% to 95%, |
|
NC Operating altitude |
10,000 feet |
|
Acoustic noise |
39.8 ?? 58.6 dBA |
|
Maximum power consumption |
190W (with PoE) |
|
Safety certifications |
UL 60950-1 Second Edition CAN/CSA-C22.2 No. 60950-1 Second Edition EN 60950-1 Second Edition EN 60950:2005 IEC 60950-1 Second Edition NOM (obtained by partners and distributors) |
|
Electromagnetic emissions certifications |
FCC Part 15 Class B CE AS/NZS CISPR22 Class B CISPR22 Class A (7010, 7024, 7030), Class B (7005) EN55022 Class A (7010, 7024, 7030), Class B (7005) ICES-003 Class A (7010, 7024, 7030), Class B (7005) VCCI Class A (7010, 7024, 7030), Class B (7005) EN61000-3-2 EN61000-3-3 EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4- 6, EN 61000-4-8, EN 61000-4-11, AS/NZS 3548 KN22 Class B KCC CNS13438 Class B EN55024/CISPR24 KN24 Industry Canada Class B CE mark, cTUVus, CB, C-tick, Anatel, NOM, MIC |
|
Telco |
Common Language Equipment Identifier (CLEI) Code |
|
Regulatory SKU information |
ARCN01014(7005), ARCN0103(7010), ARCN7024(7024), ARCN7030(7030) |
|
Minimum ArubaOS Release |
7005, AOS 6.4.1.0; 7008, AOS 6.5.0.0; 7010, AOS 6.4.1.0; 7024, AOS 6.4.3.0; 7030, AOS 6.4.1.0 |
