N1148T-ON Dell Networking N1000 Switches

All N-Series switches include Dell EMC Networking OS 6, designed for easier deployment, greater interoperability and a lower learning curve for network administrators.

In addition to supporting the Open Network Install Environment (ONIE) allowing for installation of alternate network operating systems, the N1100 switch series simplifies deployment, configuration and management by:

Offering a more flexible choice for your network by uniting products with the latest open standard protocols
Utilizing one common command line interface (CLI) and graphic user interface (GUI) using a well-known command language
Promoting greater interoperability through interfaces with Cisco’s Rapid Per VLAN Spanning Tree (RPVST+) and devices using Cisco Discovery Protocol (CDP)
Integrating with industry-leading management tools for a cohesive wired and wireless network

Additional information

Weight	14 lbs
Brand	Dell

Specification

Chassis
Approximate Weight in pounds	4.43lbs / 3.54lbs	8.33lbs / 6.72lbs	9.19lbs / 8.33lbs
Approximate Weight in kilograms	2.01kg / 1.61kg	3.78kg / 3.05kg	4.17kg / 3.78kg
Power Supply (Watts)	104W AC / 24W AC	250W AC / 40W AC	500W AC / 60W AC
Max Thermal Output (BTU/hr)	292.62 / 35.72	851.66 / 65.85	1566.15 / 102.98
Power Consumption Max (Watts)	N / 10.47	N / 19.3	N / 30.18
Dimensions in inches (H x W x D)	1.75 in x 8.5 in x 10 in	1.75 in x 17 in x 10 in	1.75 in x 17 in x 10 in
Dimensions in millimeters (H x W x D)	44.45 mm x 215.9 mm x 254 mm	44.45 mm x 431.8 mm x 254 mm	44.45 mm x 431.8 mm x 254 mm
Environmental Operating Conditions
Operating temperature	0° to 45°C (32° to 113° F)
Storage temperature	-40° to 65° C (-40° to 149° F)
Operating relative humidity	95%
Storage relative humidity	85%
Power Supply Efficiency:	80% or better in all operating modes
Performance
Switch fabric capacity	24Gbps	128Gbps	176Gbps
Forwarding rate	18Mpps	96Mpps	132Mpps
Packet buffer memory	2MB	2MB	2MB
Port Attributes
1GbE Port Attributes Multi-speed	8x 10/100/1000Mbps half/full duplex ports	24x 10/100/1000Mbps half/full duplex ports	48x 10/100/1000Mbps half/full duplex ports
1GbE Port Attributes Single-speed	2x 1000Mbps half/full duplex RJ45 ports	N/A	N/A
Integrated 1GbE SFP dedicated ports	2	N/A	N/A
