Q1J30A Specification
HPE MSA 2052 Storage Specification |
|
|
Array |
|
|
Access Type |
Block |
|
Form Factor |
2U, SFF or LFF |
|
Number of controllers per array |
2 |
|
Number of host ports per array |
8 |
|
FC host connectivity |
8/16Gb |
|
iSCSI host connectivity |
1Gb or 10GbI |
|
SAS host connectivity |
6/12Gb |
|
Cache, per array |
|
|
Max Read cache per array |
8TB |
|
Data (read/write) cache + system memory per array |
16GB |
|
Pool Capacity (with Large Pool Support) |
562 TB (512 TiB) |
|
RAID Levels supported: Virtual mode |
RAID 1, 5, 6, 10 |
|
Enclosures |
|
|
Expansion Drive Enclosures |
0-7 enclosures |
|
LFF/SFF array/enclosure mixing |
Supported |
|
Maximum number of drives per array enclosure |
24 SFF/12 LFF |
|
Maximum number of drives per drive enclosure |
24 SFF/12 LFF |
|
Drive enclosure interface type |
6Gb SAS |
|
Drives |
|
|
Maximum total HDDs per array |
192 SFF / 96 LFF |
|
Maximum total SSDs per array |
192 SFF / 96 LFF |
|
Max raw capacity per array enclosure |
76.8 TB SFF / 144TB LFF |
|
Max raw capacity per drive enclosure |
76.8 TB SFF / 144TB LFF |
|
Max raw capacity per array |
614.4TB SFF / 1152TB LFF |
|
Integrated SSDs |
2x800GB Mixed Use SSDs |
|
Drive Capacities |
|
|
SFF SSDs (Mixed Use) |
400GB, 800GB, 1.6TB, 3.2TB |
|
LFF SSDs (Mixed Use) |
400GB, 800GB |
|
SFF HDDs |
15K: 300GB, 600GB, 900GB 10K: 300GB, 600GB, 1.2TB, 1.8TB, 2.4TB |
|
LFF HDDs |
7.2K: 2TB, 4TB, 6TB, 8TB, 10TB, 12TB |
|
SEDs |
Encryption not supported |
|
Software Features |
|
|
Thin Technologies |
Thin Provisioning, Space Reclamation, Thin Rebuild |
|
Tiering |
Performance Tier, Standard Tier, Archive Tier |
|
Replication |
Snapshots (512), Volume Copy, Remote Snaps |
|
Quality of Service |
Virtual Tier Affinity |
|
Bundled/Integrated Licenses |
Advanced Data Services LTU standard |
|
Additional Features |
|
|
Maximum number of volumes |
512 |
|
Maximum number of snapshots |
512 |
|
Maximum number of hosts |
512 |
|
Maximum number of initiators |
1024 |
|
Customer self-installable |
Yes |
|
Customer self-repairable |
Yes |
|
Customer self-upgradeable |
Yes |
|
File Services |
Yes HPE Storage File Controller |
